SIP HG2001DA ARC Inverter Welder

Features:

• 20A to 200A output current; 200A @ 60% duty cycle
• Lift-TIG start function and anti-stick circuitry
• Fitted with a reliable Voltage Reduction Device (VRD)
• Generator-friendly for suitability in all environments Thermal overload protection for added safety

Specifications:

• ITEM NO: 05715
• Input Supply: 230v (32A)
• Output Current: 20A – 200A
• Output Voltage: 20.8v – 28v (ARC)
• 10.8v – 18v (TIG)
• Duty Cycle: 20°C: 200A @ 60%
• 40°C: 200A @ 15%
• Electrode Diameter: Ø 1.6mm – 5mm
• Welding Thickness: 1.5mm – 9mm
• Open Circuit Voltage: 69v
• Power Factor: 0.75
• Efficiency Level: 85%
• Protection Level: IP21S
• Insulation Class: Class H
• Net Weight: 6.50kg
• Gross Weight: 8.90kg
• Packaged Dimensions: 345(H) x 450(W) x 245mm(D)
